| Ref |
No |
Description |
Price |
|
|
001
|
43903-AF
|
BRUSH, 32 IN SWEEP 43903
|
£23.03
|
Add
|
|
002
|
43886-AF
|
Gear, Pinion R.H. (not shown) 43886
|
£23.48
|
Add
|
|
003
|
43885-AF
|
PINION LH 11TEETH
|
£21.85
|
Add
|
|
004
|
44951-AF
|
SCHUTZLEISTE VINYL 44951
|
£22.22
|
Add
|
|
005
|
43720-AF
|
KNOB (RED)
|
£7.83
|
Add
|
|
006
|
23851-AF
|
STELLSCHIENE 23851
|
£11.94
|
Add
|
|
007
|
44964-AF
|
STRAP:LIFT HANDLE SUPPORT 44964
|
£19.44
|
Add
|
|
008
|
43928-AF
|
RAHMENROHR OBEN RE. 43928
|
£44.42
|
Add
|
|
009
|
43927-AF
|
RAHMENROHR OBEN LI. 43927
|
£47.13
|
Add
|
|
010
|
43930-AF
|
TUBE, HOPPER LOWER R.H. 32" AF-43930
|
£43.76
|
Add
|
|
011
|
43929-AF
|
LOWER HOPPER TUBE RIGHT AF-43929
|
£46.50
|
Add
|
|
012
|
43650-AF
|
ASSY HOPPER BAG 43650
|
£218.41
|
Add
|
|
013
|
C-9M5732
|
Pop Rivet (OBSOLETE) (OBSOLETE) (OBSOLETE)
|
N/A
|
POA
|
|
014
|
43659-AF
|
PIN, SPRING 3/16x1 AF-43659
|
£3.48
|
Add
|
|
015
|
AF-1650-21
|
RETAINING RING
|
£2.61
|
Add
|
|
016
|
40001-AF
|
Washer, Shim 1-1/8" x .594" x .025" 44007-AF
|
£3.58
|
Add
|
|
017
|
741-0249
|
BEARING
|
£8.44
|
Add
|
|
018
|
712-0158
|
NUT, HEX CENTER LOCK, 5/16-18
|
£9.35
|
Add
|
|
019
|
716-0106A
|
RING E TYPE .625 DIA SHAFT
|
£3.33
|
Add
|
|
020
|
44125-AF
|
Washer, Flat .62" x 1.00" 44125
|
£4.05
|
Add
|
|
021
|
736-0101
|
WASH:FLAT:.406 X 1.00 X .030
|
£12.63
|
Add
|
|
022
|
44598-AF
|
Axle 44598
|
£11.94
|
Add
|
|
023
|
44684-AF
|
Jam Nut, 3/8-24 Thread 44684
|
£4.05
|
Add
|
|
024
|
43661-AF
|
HEX BOLT
|
£3.11
|
Add
|
|
025
|
712-0291
|
LOCK-NUT
|
£2.77
|
Add
|
|
026
|
1038-AF
|
Nut, Nylock 3/8-24 Thread 1038
|
£3.48
|
Add
|
|
027
|
44906-AF
|
ADJUSTING BAIL 44906
|
£40.31
|
Add
|
|
028
|
43083-AF
|
HEX NUT
|
£3.32
|
Add
|
|
029
|
43080-AF
|
CARRIAGE BOLT
|
£3.49
|
Add
|
|
030
|
23400-AF
|
SPACER
|
£5.85
|
Add
|
|
031
|
43686-AF
|
BAG 43686
|
£29.60
|
Add
|
|
032
|
44909-AF
|
BRUSH SHAFT
|
£6.85
|
Add
|
|
033
|
23853-AF
|
BRACKET, GATE SLIDE ANGLE 23853
|
£18.25
|
Add
|
|
034
|
23848-AF
|
WRAPPER
|
£126.34
|
Add
|
|
035
|
25102-AF
|
Dust Cover
|
£13.50
|
Add
|
|
036
|
43012-AF
|
BOLT
|
£3.32
|
Add
|
|
037
|
44947-AF
|
Bolt, Curved Head 5/16-18 x 1-5/8" 44947
|
£4.05
|
Add
|
|
038
|
23869-AF
|
BRACKET, GATE SLIDE ANGLE 23869
|
£4.05
|
Add
|
|
039
|
23871-AF
|
SHAFT, BRUSH 32 IN SWEEP 23871
|
£87.00
|
Add
|
|
040
|
23580-AF
|
BRUSH RETAINER 42-0197
|
£9.24
|
Add
|
|
041
|
23581-AF
|
BRUSH RETAINER 42-0197
|
£5.45
|
Add
|
|
042
|
44930-AF
|
WHEEL ASSY 38" SWEEPER
|
£70.41
|
Add
|
|
043
|
23345-AF
|
RUBBER STRIP AF-23345
|
£18.60
|
Add
|
|
044
|
43086-AF
|
Lock Washer, 5/16" 43086
|
£3.48
|
Add
|
|
045
|
43943-AF
|
Handle Grip 43943
|
£8.46
|
Add
|
|
046
|
2674-32-AF
|
Hub Cap 2674-32
|
N/A
|
POA
|
|
047
|
23014-AF
|
HITCH BRACKET
|
£31.67
|
Add
|
|
048
|
23812-AF
|
ARM, BAG MT LG 23812
|
£25.40
|
Add
|
|
049
|
23351-AF
|
STRAP, BAG FRAME 32 IN AF-23351
|
£25.88
|
Add
|
|
050
|
43926-AF
|
HOPPER SUPPORT ROD
|
£8.99
|
Add
|
|
051
|
1671-1-AF
|
PAWL MOD 60 1671-1
|
£11.82
|
Add
|
|
052
|
43346-AF
|
Truss Head Bolt, #10- 32 x 5/8" 43346
|
£3.48
|
Add
|
|
053
|
43662-AF
|
Lock Nut, 10-32 43662
|
£3.73
|
Add
|
|
054
|
43081-AF
|
FLAT WASHER
|
£3.49
|
Add
|
|
055
|
712-0158
|
NUT, HEX CENTER LOCK, 5/16-18
|
£9.35
|
Add
|
|
056
|
43182-AF
|
Hex Bolt, 5/16" x 3/4" 43182
|
£4.31
|
Add
|
|
057
|
712-0291
|
LOCK-NUT
|
£2.77
|
Add
|
|
058
|
43513-AF
|
CLEVIS PIN (RED)
|
£8.53
|
Add
|
|
059
|
43407-AF
|
Bolt, Hex 3/8-16 x 3/4" Lg. * 43407
|
£3.91
|
Add
|
|
060
|
43082-AF
|
HEX LOCK NUT
|
£4.12
|
Add
|
|
061
|
1509-090
|
NO LONGER AVAILABLE
|
N/A
|
POA
|
|
062
|
714-0474
|
PIN (RED)
|
£3.20
|
Add
|
|
063
|
43978-AF
|
Bolt, Curved 1.4-20 x 1" 43978
|
£4.05
|
Add
|
|
064
|
23331-AF
|
THROTTLE CABLE CLIP 23331
|
£12.01
|
Add
|
|
065
|
23868-AF
|
TONGUE, HITCH 23868
|
£116.34
|
Add
|
|
066
|
23354-AF
|
BAIL 23354
|
£11.94
|
Add
|
|
067
|
43681-AF
|
Bolt, Carriage 5/16-18 x 1-1/2" 43681
|
£3.48
|
Add
|
|
068
|
43062-AF
|
BOLT 3/8-16 X 1-1/2 HEX HEAD 43062
|
£4.99
|
Add
|
|
069
|
23850-AF
|
Handle, Height Adjustment 23850
|
£28.31
|
Add
|
|
070
|
R19172410-AF
|
WASHER-FLAT AF-R19172410
|
N/A
|
POA
|
|
071
|
43814-AF
|
SLOTTED TRUSS HEADBOLT(5/16-18x3/4)
|
£3.11
|
Add
|
|
072
|
44950-AF
|
BOLT
|
£3.62
|
Add
|
|
073
|
43407-AF
|
Bolt, Hex 3/8-16 x 3/4" Lg. * 43407
|
£3.91
|
Add
|
|
074
|
43175-AF
|
Hex Bolt, 1/4-20 x 1/2" * 43175
|
£4.15
|
Add
|
|
075
|
43343-AF
|
PIN COTTER
|
£4.20
|
Add
|
|
076
|
23353-AF
|
HITCH PIN
|
£19.20
|
Add
|
|
077
|
23368-AF
|
Tube, Hitch Spacer 23368
|
£8.18
|
Add
|
|
078
|
43737-AF
|
Hopper Rope 43737
|
£5.99
|
Add
|
|
079
|
44006-AF
|
WASHER
|
£5.01
|
Add
|
|
080
|
44013-AF
|
END PLATE 44013
|
£48.64
|
Add
|
|
081
|
736-0287
|
FLAT WASHER .78" X 1.25" X .062"
|
£7.92
|
Add
|
|
082
|
44692-AF
|
Bolt, Hex 5/16-18 x 1/2" Lg. 44692
|
£4.05
|
Add
|
|
083
|
23845-AF
|
PANEL-LH SIDE CUB BEIGE 23845
|
£23.39
|
Add
|
|
084
|
23846-AF
|
SIDE PANEL CART EXTENSION RH 23846
|
£55.92
|
Add
|
|
085
|
44903-AF
|
HITCH TUBE
|
N/A
|
POA
|
|
086
|
44695-AF
|
Washer, Bowed 44695
|
£4.05
|
Add
|
