| Ref |
No |
Description |
Price |
|
|
001
|
46776-AF
|
HITCH TUBE R.H. AF-46776
|
£45.85
|
Add
|
|
002
|
46777-AF
|
HITCH TUBE L.H. AF-46777
|
£45.85
|
Add
|
|
003
|
AF-24195
|
PLAQUE
|
N/A
|
POA
|
|
004
|
AF-24196
|
PLAQUE
|
N/A
|
POA
|
|
005
|
24184-AF
|
COVER-HARD TOP AF-24184
|
£33.96
|
Add
|
|
006
|
24185-AF
|
BRACE,REAR SUPPORT AF-24185
|
£33.67
|
Add
|
|
007
|
C9M-5732-AF
|
RIVET AF-C9M-5732
|
N/A
|
POA
|
|
008
|
46778-AF
|
SKIRT,42" AF-46778
|
£24.73
|
Add
|
|
009
|
24186-AF
|
RUBBER STRIP AF-24186
|
£19.24
|
Add
|
|
010
|
AF-63468
|
HEIGHT ADJUSTEMENT TUBE ASSY
|
N/A
|
POA
|
|
011
|
44947-AF
|
Bolt, Curved Head 5/16-18 x 1-5/8" 44947
|
£4.05
|
Add
|
|
012
|
44695-AF
|
Washer, Bowed 44695
|
£4.05
|
Add
|
|
013
|
43086-AF
|
Lock Washer, 5/16" 43086
|
£3.48
|
Add
|
|
014
|
43083-AF
|
HEX NUT
|
£3.32
|
Add
|
|
015
|
62489-AF
|
LAGERSCHALE AUßEN 62489
|
£42.99
|
Add
|
|
016
|
HG-44232P
|
BALL BEARING
|
£70.26
|
Add
|
|
017
|
AF-1629-56
|
Retainer, Dust Cover 1629-56
|
£26.36
|
Add
|
|
018
|
24198-AF
|
SHAFT, BRUSH - 42" HS AF-24198
|
£98.51
|
Add
|
|
019
|
46780-AF
|
BRUSH 42"
|
£25.59
|
Add
|
|
020
|
710-0252
|
NO LONGER AVAILABLE
|
N/A
|
POA
|
|
021
|
712-0291
|
LOCK-NUT
|
£2.77
|
Add
|
|
022
|
23580-AF
|
BRUSH RETAINER 42-0197
|
£9.24
|
Add
|
|
023
|
23581-AF
|
BRUSH RETAINER 42-0197
|
£5.45
|
Add
|
|
024
|
44008-AF
|
WASHER
|
£3.24
|
Add
|
|
025
|
62490-AF
|
GEAR SPROCKET SUB ASSY
|
£72.48
|
Add
|
|
026
|
23573-AF
|
DESTPROOF CAP 23573
|
£8.85
|
Add
|
|
027
|
1671-1-AF
|
PAWL MOD 60 1671-1
|
£11.82
|
Add
|
|
028
|
43655-AF
|
SPANNRING.75" 43655
|
£4.15
|
Add
|
|
029
|
AF-1650-21
|
RETAINING RING
|
£2.61
|
Add
|
|
030
|
40001-AF
|
Washer, Shim 1-1/8" x .594" x .025" 44007-AF
|
£3.58
|
Add
|
|
031
|
43182-AF
|
Hex Bolt, 5/16" x 3/4" 43182
|
£4.31
|
Add
|
|
032
|
141-AF
|
Washer, Flat 1-1/2" x .375" x .062" 141
|
£3.91
|
Add
|
|
033
|
736-0692
|
Flat Washer, 3/8" 43070
|
£3.20
|
Add
|
|
034
|
736-0287
|
FLAT WASHER .78" X 1.25" X .062"
|
£7.92
|
Add
|
|
035
|
1540-107-AF
|
NO LONGER AVAILABLE
|
N/A
|
POA
|
|
036
|
1038-AF
|
Nut, Nylock 3/8-24 Thread 1038
|
£3.48
|
Add
|
|
037
|
2674-32-AF
|
Hub Cap 2674-32
|
N/A
|
POA
|
|
038
|
43894-AF
|
STOPPING RING 43894
|
£3.76
|
Add
|
|
039
|
43932-AF
|
BOLT, ROUND HEAD 43932
|
£5.18
|
Add
|
|
040
|
23400-AF
|
SPACER
|
£5.85
|
Add
|
|
041
|
43890-AF
|
SPROCKET 43890
|
£26.12
|
Add
|
|
042
|
43889-AF
|
SPROCKET LH
|
£24.33
|
Add
|
|
043
|
44137-AF
|
Washer, Flat 1/2" I.D. 44137
|
£2.60
|
Add
|
|
044
|
44542-AF
|
CHAIN
|
£15.47
|
Add
|
|
045
|
43175-AF
|
Hex Bolt, 1/4-20 x 1/2" * 43175
|
£4.15
|
Add
|
|
046
|
43661-AF
|
HEX BOLT
|
£3.11
|
Add
|
|
047
|
62791-AF
|
RADGEHÄUSE LINKS 62791
|
£99.19
|
Add
|
|
048
|
62792-AF
|
RADGEHÄUSE 62792
|
£57.96
|
Add
|
|
049
|
46734-AF
|
FRAME, UPPER RIGHT AF-46734
|
£55.91
|
Add
|
|
050
|
46735-AF
|
FRAME, UPPER LEFT AF-46735
|
£54.04
|
Add
|
|
051
|
46732-AF
|
FRAME, LOWER RIGHT AF-46732
|
£48.20
|
Add
|
|
052
|
46733-AF
|
FRAME, LOWER LEFT AF-46733
|
£48.20
|
Add
|
|
053
|
24189-AF
|
FIXATION STRIP, OUTSIDE AF-24189
|
£29.55
|
Add
|
|
054
|
43938-AF
|
ROD, HOPPER SUPPORT
|
£12.19
|
Add
|
|
055
|
43737-AF
|
Hopper Rope 43737
|
£5.99
|
Add
|
|
056
|
24190-AF
|
FIXATION STRIP, INSIDE AF-24190
|
£12.88
|
Add
|
|
057
|
AF-24191
|
STRAP,HEIGHT ADJUSTMENT
|
N/A
|
POA
|
|
058
|
23687-AF
|
Hitch Bracket 23687
|
£33.95
|
Add
|
|
059
|
24192-AF
|
BRACKET (EXRED)
|
£8.88
|
Add
|
|
060
|
AF-24193
|
HEIGHT ADJUSTING LEVER
|
N/A
|
POA
|
|
061
|
AF-46781
|
TUBE,BAG ARM
|
£40.83
|
Add
|
|
062
|
46823-AF
|
ROD,HYDRO DISENGAGEMENT AF-46823
|
£10.51
|
Add
|
|
063
|
44985-AF
|
WHEEL ASSY. FOR 38" SWEEPER
|
£116.26
|
Add
|
|
064
|
45088-AF
|
WHEEL BEARING
|
£12.03
|
Add
|
|
065
|
46782-AF
|
BOLT
|
£3.41
|
Add
|
|
066
|
43224-AF
|
BOLT
|
£5.85
|
Add
|
|
067
|
712-0158
|
NUT, HEX CENTER LOCK, 5/16-18
|
£9.35
|
Add
|
|
068
|
46847-AF
|
SLEEVE AF-46847
|
£3.85
|
Add
|
|
069
|
R19111116-AF
|
WASHER
|
£3.76
|
Add
|
|
070
|
43720-AF
|
KNOB (RED)
|
£7.83
|
Add
|
|
071
|
710-0451
|
BOLT:CRG:5/16-18:.750 GR1
|
£3.70
|
Add
|
|
072
|
43081-AF
|
FLAT WASHER
|
£3.49
|
Add
|
|
073
|
43084-AF
|
BOLT
|
£2.56
|
Add
|
|
074
|
43943-AF
|
Handle Grip 43943
|
£8.46
|
Add
|
|
075
|
44732-AF
|
TOOTH LOCK WASHER
|
£3.49
|
Add
|
|
076
|
23353-AF
|
HITCH PIN
|
£19.20
|
Add
|
|
077
|
23368-AF
|
Tube, Hitch Spacer 23368
|
£8.18
|
Add
|
|
078
|
43343-AF
|
PIN COTTER
|
£4.20
|
Add
|
|
079
|
23331-AF
|
THROTTLE CABLE CLIP 23331
|
£12.01
|
Add
|
|
080
|
726-0100
|
PUSH NUT 3/8 (RED)
|
£3.24
|
Add
|
|
081
|
43978-AF
|
Bolt, Curved 1.4-20 x 1" 43978
|
£4.05
|
Add
|
|
082
|
710-0106
|
HHCS:1/4-20:1.25:GR5:SPEC
|
£3.95
|
Add
|
|
083
|
43346-AF
|
Truss Head Bolt, #10- 32 x 5/8" 43346
|
£3.48
|
Add
|
|
084
|
43662-AF
|
Lock Nut, 10-32 43662
|
£3.73
|
Add
|
|
085
|
43407-AF
|
Bolt, Hex 3/8-16 x 3/4" Lg. * 43407
|
£3.91
|
Add
|
|
086
|
712-0342
|
NUT-HEX CENTER AF-43082
|
£7.77
|
Add
|
|
087
|
44481-AF
|
Cap, Vinyl 44481
|
£4.05
|
Add
|
|
088
|
43055-AF
|
COTTER PIN
|
£6.04
|
Add
|
|
089
|
46867-AF
|
Clevis Pin, 1/4" x 1-3/4" Lg. 46867
|
£4.65
|
Add
|
|
090
|
46738-AF
|
HOPPER BAG AF-46738
|
£260.28
|
Add
|
|
091
|
46739-AF
|
WINDSCREEN 42" AF-46739
|
£40.14
|
Add
|
