| Ref |
No |
Description |
Price |
|
|
|
45026-AF
|
CLAMP (RED)
|
£5.85
|
Add
|
|
|
47405-AF
|
CLAMP
|
£7.85
|
Add
|
|
|
40216
|
Owners Manual
|
N/A
|
POA
|
|
001
|
47419
|
Tank (45 Gallon)
|
N/A
|
POA
|
|
002
|
46700-AF
|
LID FOR SPRAYERS
|
£37.30
|
Add
|
|
003
|
24506
|
Angle, Frame (Rear)
|
N/A
|
POA
|
|
004
|
24507
|
Angle, Frame (Side)
|
N/A
|
POA
|
|
005
|
24508
|
Axle
|
N/A
|
POA
|
|
006
|
48906
|
WHEEL
|
£332.76
|
Add
|
|
007
|
24952
|
Angle, Frame (Front)
|
N/A
|
POA
|
|
008
|
23014-AF
|
HITCH BRACKET
|
£31.67
|
Add
|
|
009
|
24931
|
Strap, Frame
|
N/A
|
POA
|
|
010
|
25210
|
Tongue
|
N/A
|
POA
|
|
011
|
24509
|
Bracket, Boom Mount
|
N/A
|
POA
|
|
012
|
24517
|
Bracket, Boom Transport
|
N/A
|
POA
|
|
013
|
63834
|
Assembly, Boom Mount (R.H.)
|
N/A
|
POA
|
|
014
|
63797
|
Assembly, Boom Mount (L.H.)
|
N/A
|
POA
|
|
015
|
63798
|
Assembly, Boom Arm (R.H.)
|
N/A
|
POA
|
|
016
|
63799
|
Assembly, Boom Arm (L.H.)
|
N/A
|
POA
|
|
017
|
63800
|
Assembly, Boom Hose (Not Shown) Contains items 18 through 31
|
N/A
|
POA
|
|
018
|
47396-AF
|
ELBOW, PLASTIC 11/16" THD.
|
£8.11
|
Add
|
|
019
|
45029-AF
|
STRAINER SCREEN
|
£11.35
|
Add
|
|
020
|
45028-AF
|
NOZZLE FLOODJET
|
£8.19
|
Add
|
|
021
|
45037-AF
|
NUT
|
£5.96
|
Add
|
|
022
|
47420
|
TEE PLASIC 11/16"THDX3/8" BARD
|
£18.93
|
Add
|
|
023
|
45026-AF
|
CLAMP (RED)
|
£5.85
|
Add
|
|
024
|
47421
|
Hose, 3/8" ID (28" Lg.)
|
N/A
|
POA
|
|
025
|
64674
|
Hose, 3/8" ID x 35" Lg. 47422
|
N/A
|
POA
|
|
026
|
47423
|
HOSE 3/8" ID X 19" LG
|
£18.41
|
Add
|
|
027
|
47416-AF
|
Valve, Nylon 1/4" 47416
|
£46.43
|
Add
|
|
028
|
47394-AF
|
TEE
|
£5.76
|
Add
|
|
029
|
45034-AF
|
Hose Barb, 3/8" 45034
|
£4.05
|
Add
|
|
030
|
47412
|
ADAPTER
|
£20.43
|
Add
|
|
031
|
45032-AF
|
NUT SWIVEL
|
£3.87
|
Add
|
|
032
|
45033-AF
|
HOSE BARB 1/2"
|
£3.62
|
Add
|
|
033
|
45025-AF
|
CLAMP
|
£5.45
|
Add
|
|
034
|
45022
|
Hose, 1/2" ID (14" Lg.)
|
N/A
|
POA
|
|
035
|
47424
|
Hose, 1/2" ID x 23" Lg.
|
N/A
|
POA
|
|
036
|
47425
|
Hose, 1/2" ID x 2-1/2" Lg.
|
N/A
|
POA
|
|
037
|
45024-AF
|
CAP STRAINER
|
£4.12
|
Add
|
|
038
|
46276-AF
|
Adapter, 3/4" GH x 1/2" Barb 46276
|
£5.68
|
Add
|
|
039
|
45031-AF
|
ADAPTOR (RED)
|
£4.58
|
Add
|
|
040
|
74325
|
Elbow, Nylon 1/2" NPT x 1/2" Barb 47426
|
N/A
|
POA
|
|
041
|
24547
|
Bracket, Tee Support
|
N/A
|
POA
|
|
042
|
35-850481
|
Tee, 1/2" x 1/2" x 1/2" (1/4" Port) 45050
|
N/A
|
POA
|
|
043
|
47390
|
Adapter, 1/2" NPT x 1/4" Barb
|
N/A
|
POA
|
|
044
|
44692-AF
|
Bolt, Hex 5/16-18 x 1/2" Lg. 44692
|
£4.05
|
Add
|
|
045
|
49761
|
Hose, 1/4" ID x 15’ Lg.
|
N/A
|
POA
|
|
046
|
47623
|
Hitch Pin
|
N/A
|
POA
|
|
047
|
47406-AF
|
SPRAY GUN
|
£56.06
|
Add
|
|
048
|
47427-AF
|
Pump and Motor 47427
|
N/A
|
POA
|
|
049
|
47475
|
Elbow, Swivel
|
N/A
|
POA
|
|
050
|
45069-AF
|
Screw, Ph. Pan Hd. 10-24 x 1" Lg. 45069
|
£4.05
|
Add
|
|
051
|
43910-AF
|
Washer, Flat #10 SAE 43910
|
£3.19
|
Add
|
|
052
|
49779
|
Coiled Hose Clamp
|
N/A
|
POA
|
|
053
|
47403-AF
|
CAP NYLON
|
£3.49
|
Add
|
|
054
|
47402-AF
|
Nut, Nylon 11/16" Thd. 47402
|
£3.91
|
Add
|
|
055
|
47206
|
O-RING
|
£15.40
|
Add
|
|
056
|
47399-AF
|
Drain Body 47399
|
£8.85
|
Add
|
|
057
|
47398-AF
|
Washer, Nylon 47398
|
£4.35
|
Add
|
|
058
|
49754-AF
|
SWITCH & WIRE ARM
|
£145.31
|
Add
|
|
059
|
43063-AF
|
BOLT
|
£4.12
|
Add
|
|
060
|
712-3004A
|
HEX FLANGE NUT
|
£2.97
|
Add
|
|
061
|
43182-AF
|
Hex Bolt, 5/16" x 3/4" 43182
|
£4.31
|
Add
|
|
062
|
46699-AF
|
BOLT
|
£3.49
|
Add
|
|
063
|
47189-AF
|
Hex Nylock Nut 1/4" 47189
|
£3.91
|
Add
|
|
064
|
46088
|
Spacer, Wheel
|
N/A
|
POA
|
|
065
|
43601-AF
|
WASHER
|
£8.99
|
Add
|
|
066
|
43093-AF
|
COTTER PIN
|
£3.11
|
Add
|
|
067
|
710-0514
|
HEX BOLT
|
£3.81
|
Add
|
|
068
|
43350-AF
|
Bolt, Carriage 3/8-16 x 1" Lg. 43350
|
£3.73
|
Add
|
|
069
|
43432-AF
|
Bolt, Hex 3/8-16 x 2-1/2" Lg. 43432
|
£4.05
|
Add
|
|
070
|
43087-AF
|
Hex Bolt, 3/8-16 x 1-1/4" Long 43087
|
£4.58
|
Add
|
|
071
|
43407-AF
|
Bolt, Hex 3/8-16 x 3/4" Lg. * 43407
|
£3.91
|
Add
|
|
072
|
736-0169
|
L. WASHER
|
£2.89
|
Add
|
|
073
|
HA21362
|
NUT
|
£3.96
|
Add
|
|
074
|
736-0692
|
Flat Washer, 3/8" 43070
|
£3.20
|
Add
|
|
075
|
43015
|
Hex nut, 3/8-16 *
|
N/A
|
POA
|
|
076
|
49428
|
Bolt, Hex 3/8-16 x 4-1/4" Lg.
|
N/A
|
POA
|
|
077
|
46959
|
Spring
|
N/A
|
POA
|
|
078
|
43343-AF
|
PIN COTTER
|
£4.20
|
Add
|
|
079
|
43055-AF
|
COTTER PIN
|
£6.04
|
Add
|
|
080
|
725-0157
|
NO LONGER AVAILABLE
|
N/A
|
POA
|
|
081
|
45072-AF
|
GASKET
|
£3.70
|
Add
|
|
082
|
45017-AF
|
Y VALVE
|
£30.93
|
Add
|
|
083
|
45071-AF
|
Gauge, Pressure 2" 100 PSI 45071
|
£58.88
|
Add
|
|
084
|
23884-AF
|
Hook, Hose 23884
|
£19.93
|
Add
|
|
085
|
45041-AF
|
Spacer, Flanged 3/16" ID x 1/4" Lg. 45041
|
£4.05
|
Add
|
|
086
|
44911-AF
|
SPACER
|
£4.12
|
Add
|
|
087
|
736-0722
|
Lock Washer, #10
|
£3.20
|
Add
|
|
088
|
45040-AF
|
BOLT
|
£3.62
|
Add
|
|
089
|
43086-AF
|
Lock Washer, 5/16" 43086
|
£3.48
|
Add
|
|
090
|
45085-AF
|
Terminal, .25 Male Tab (not shown) 45085
|
£5.68
|
Add
|
