FG320_0500

Assembly drawing

Please use your mouse to zoom in and out for more detailed view

FG320_0500

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref No Description Price
46212-AF OWNERS MANUAL N/A POA
001 45014-AF TANK (14 GAL.) £293.07 Add
002 45015-AF PUMP AND MOTOR £421.85 Add
003 46278-AF HOSE £15.33 Add
004 45024-AF CAP STRAINER £4.12 Add
005 45030-AF ELBOW PLASTIC £10.89 Add
006 45031-AF ADAPTOR (RED) £4.58 Add
007 45032-AF NUT SWIVEL £3.87 Add
008 45033-AF HOSE BARB 1/2" £3.62 Add
009 736-0722 Lock Washer, #10 £3.20 Add
010 45069-AF Screw, Ph. Pan Hd. 10-24 x 1" Lg. 45069 £4.05 Add
011 43910-AF Washer, Flat #10 SAE 43910 £3.19 Add
012 46276-AF Adapter, 3/4" GH x 1/2" Barb 46276 £5.68 Add
014 45084-AF Switch, On - Off 45084 £25.40 Add
015 45082-AF Boot, Rubber Switch 45082 £13.83 Add
016 45080-AF PLATE, ON - OFF SWITCH £4.05 Add
017 45048-AF Nut, Hex 15/32-32 Thd. 45048 £4.05 Add
018 45087-AF Bushing, Strain Relief 45087 £4.05 Add
019 45085-AF Terminal, .25 Male Tab (not shown) 45085 £5.68 Add
020 45086-AF Terminal, .25 Female Tab (not shown) 45086 £6.20 Add
021 23889-AF Bracket, Switch Mounting 23889 £19.19 Add
023 46277-AF Elbow, 3/8 NPT x 1/2" Barb 46277 £5.79 Add
024 45025-AF CLAMP £5.45 Add
025 45018-AF CONNECTOR W/WIRE £71.79 Add
026 45049-AF NIPPLE £4.74 Add
027 45050-AF TEE,1/2 x 1/2 x 1/2 (1/4"PORT) AF-45050 £32.90 Add
028 45016-AF ASSY SPRAY GUN 45016 £132.03 Add
029 45023-AF HOSE, 3/8 ID (12'6" LG) £68.26 Add
030 45026-AF CLAMP (RED) £5.85 Add
031 43083-AF HEX NUT £3.32 Add
032 45034-AF Hose Barb, 3/8" 45034 £4.05 Add
033 45193-AF TUBE, FRAME £38.97 Add
034 45194-AF TUBE, CROSSOVER £22.07 Add
035 23932-AF BRACKET, HITCH £11.59 Add
036 23933-AF BAR, HITCH £10.25 Add
037 23931-AF STRAP, MOUNT ADJUST £7.41 Add
038 23910-AF SPRING ASSY 23890 £13.05 Add
039 23911-AF BOOM BAR £9.58 Add
040 45021-AF HOSE £12.61 Add
042 45027-AF T-STÜCK PLASTIK 45027 N/A POA
043 45028-AF NOZZLE FLOODJET £8.19 Add
044 45029-AF STRAINER SCREEN £11.35 Add
045 45037-AF NUT £5.96 Add
046 44692-AF Bolt, Hex 5/16-18 x 1/2" Lg. 44692 £4.05 Add
049 725-0157 NO LONGER AVAILABLE N/A POA
050 45180-AF Clip (Small), Spray Gun 45180 £20.21 Add
051 736-0169 L. WASHER £2.89 Add
052 45040-AF BOLT £3.62 Add
053 1509-69-AF HEX BOLT, 1/4-20 X 1-3/4" LG. £2.77 Add
054 712-0291 LOCK-NUT £2.77 Add
055 43081-AF FLAT WASHER £3.49 Add
056 43054-AF Bolt, Hex 3/8-16 x 2" Lg. * 43054 £5.79 Add
057 43086-AF Lock Washer, 5/16" 43086 £3.48 Add
058 712-0158 NUT, HEX CENTER LOCK, 5/16-18 £9.35 Add
059 45039-AF BOLT, CARR 5/16-18x2" LG AF-45039 £4.05 Add
060 43088-AF FLAT WASHER £3.11 Add
061 43055-AF COTTER PIN £6.04 Add
062 43070-AF Washer, 3/8" £3.91 Add
063 43193-AF WING NUT 43193 £5.79 Add
064 43023-AF CLEVIS PIN 092.34.115 £12.69 Add
065 43182-AF Hex Bolt, 5/16" x 3/4" 43182 £4.31 Add
066 43432-AF Bolt, Hex 3/8-16 x 2-1/2" Lg. 43432 £4.05 Add
067 43352-AF Flat Washer, 7/16" 43352 £3.48 Add
068 45017-AF Y VALVE £30.93 Add
069 712-0798 HEX. NUT £7.61 Add
070 45071-AF Gauge, Pressure 2" 100 PSI 45071 £58.88 Add
071 45072-AF GASKET £3.70 Add
072 44950-AF BOLT £3.62 Add
073 23625-AF Spacer, 1/4" Long 23625 £10.35 Add
074 43001-AF HEX BOLT (RED) £3.49 Add
075 43020-AF BOLT 1/2-13 X 1-1/2 HEX HEAD £7.06 Add
076 R19172410-AF WASHER-FLAT AF-R19172410 N/A POA
077 43353-AF Lock Washer, 1/2" 43353 £3.08 Add
078 712-0206 NUT £3.42 Add
079 23519-AF SLEEVE 092.34.133 £11.76 Add
080 23228-AF SPACER BUSHING £18.75 Add
081 43062-AF BOLT 3/8-16 X 1-1/2 HEX HEAD 43062 £4.99 Add
082 43840-AF HEX BOLT £3.49 Add
083 43085-AF Bolt, Hex 5/16-18 x 1-1/2" £4.15 Add
084 41576-AF Bolt, Hex 3/8-16 x 1-3/4" Lg.* 41576 £4.05 Add
